the colloid mill has eight layers of shear and one layer of grinding structure, one-time grinding, grinding, homogenizing ability and low energy consumption;
it can realize continuous production of 20% polymer by grinding at a time, and the content of particles with particle diameter ≤ 20μm ≥ 80%;
product details
features:
(1) the colloidal grinding rotor is an eight-layer shearing and one-layer grinding structure, which has the advantages of one-time grinding, grinding, homogenization and low energy consumption;
(2) it can realize continuous production of 20% polymer by one-time grinding, and the content of particles with particle diameter ≤ 20μm ≥ 80%; (3) it can produce emulsified high-viscosity modified asphalt (content of sbs/sbr in asphalt is ≥12%, solid content ≥75%, softening point>90, shrp performance grade pg88-28);
(4) the colloid mill adopts mechanical seals of the cartridge type. it has a long service life and is guaranteed for 2 years or 200,000 tons.
|
参数 型号 |
ds-cm-t |
ds-cm-10 |
ds-cm-20 |
ds-cm-40 |
ds-cm-60 |
|
改性沥青产能(t/h) |
0.5 |
8~12 |
18~25 |
35~45 |
55~65 |
|
乳化沥青产能(t/h) |
0.4 |
8~12 |
16~22 |
35~43 |
- |
|
电机功率(kw) |
2.2 |
37 |
75 |
110 |
132 |
|
转速(r/min) |
2900 |
2900 |
2900 |
1450 |
1450 |
|
线速度(m/s) |
15.2 |
30.4 |
44 |
28.8 |
34.1 |
|
耐压(mpa) |
1.2 |
||||
|
耐温(℃) |
300 |
||||
|
可调间隙(mm) |
0.1~2 |
||||
|
工作寿命(h) |
≥20000 |
||||
|
磨齿级数 |
9 |
||||
|
定转子材质 |
进口铬镍合金钢，hrc≥45 |
||||
