soluble delivery measurement uses imported multi-stage centrifugal pumps, diverter control valves, electromagnetic flowmeters and back pressure systems to achieve coordinated control of pressure and flow;
product details
features:
(1) soap delivery measurement adopts imported multi-stage centrifugal pump, diverter control valve, electromagnetic flowmeter and back pressure system to achieve coordinated control of pressure and flow;
(2) asphalt transport measurement adopts frequency conversion metering pump and flow meter coordinated control;
(3) the colloid mill has strong shearing, grinding and homogenizing ability, and the particle content of particle size ≤ 5μm is ≥ 95%;
(4) efficient heat exchanger and back pressure system to prevent vaporization and demulsification, equipped with purge and cleaning functions;
(5) temperature control accuracy ±1°c, measurement accuracy 0.2%, solid content accuracy 0.5%;
(6) simulate production mode adjustment, verification of various process parameters to ensure production safety and product quality;
(7) intelligent control system has the functions of automatic production, safety interlocking, data monitoring and recording, remote monitoring of mobile phone app, and wireless remote maintenance;
(8) emulsified high-viscosity modified bitumen index: sbs/sbr content in the asphalt ≥ 12%, solid content ≥ 75%, softening point> 90, pg88-28;
(9) microfinance allocation of modified agent feeding, mixing tanks and modified asphalt finished products system, expansion with modified asphalt production function;
型号 参数 |
产能 t/h |
主机功率kw |
安装方式 |
ds-ecm-10 |
8~12 |
70 |
固定式和撬装式 |
